Case Study

Norfolk Naval Shipyard Saves Equivalent of 800,000 lbs. of Coal Annually and Eliminates Over 450,000 lbs./hour of Steam Losses with Piping and Steam Trap Upgrades

SMI Impact

Created safe workspaces with full coverage of uninsulated of piping and equipment

Thermal savings equivalent to 800,000 lbs. of coal burned annually

Elimination of steam losses in excess of 450,000 lbs./hour

Improved system functionality for steam trap maintenance with installation of new steam trap strainers and isolation valves

Customer

An ESCO engaged Steam Management, Inc. to design-bid and execute the installation of multiple ECMs at Norfolk Naval Shipyard and St. Julien’s Annex, in Portsmouth VA.  The project encompassed 50+ buildings with medium and high-level security protocol across 3 campuses.

Problems

The site has high-pressure steam distribution systems with pressure reducing stations located in each building.  Both the high and medium/low pressure systems needed upgrades and repairs to improve functionality and reduce energy losses.  The piping and equipment insulation in most locations was missing or degraded to a condition where re-insulation was necessary for energy savings and to avoid existing health and safety risks.

Site conditions:

  • Unsafe work areas with exposed steam piping

  • Neglected steam traps without strainers and isolation valves

Key Actions


Schedule an assessment of your facility.

(800) 731-0131 ext. 701 | info@steammgt.com

  • Survey and develop IGA scope of work

  • Prepare final application schedules for project approval

  • Prepare product submittal packages for project approval

  • Prepare work and safety plans with JHA for project approval

  • Manage material purchasing and handling on site across 3 high- medium security facilities

  • Manage all subcontracted labor for turnkey installation

  • Work with facility and building managers for site access and utility shutdowns

  • On-site project management by SMI personnel

  • Conduct start-up and weekly safety meetings

  • Pre & post M&V data with IR photos for all installed components

  • Complete project commissioning, punch list and sign-off walk throughs

  • Provide site training with videographer

  • Provide O&M Manual with material and workmanship warranty
